Description

Summary

• Implement monitoring of the pressure and temperature signals of engine oil and refrigerant.
• Product has good reliability, long service life and suitable to work under the bad environment in the car system.

Product Features

• Operating pressure range: 0~3.6Mpa(range is adjustable)
• Accuracy: ±1.0%F.S.( Linearity , Hysteresis , Repeatability )
• Total error band:±2.3%F.S.( -40℃~+135℃ )other high-precision versions are available
• Operating temperature: -40℃~+135℃
• Storage temperature: -40℃~+150°C
• Protect pressure:5.4Mpa
• Burst pressure: 10Mpa
• Operating medium:Engine oil, POE oil, refrigerant
• Life cycle: 3 million cycles
• Vibrating:13g ( 100~400Hz )
• Ingress Protection : IP65
• Supply voltage:5.0士0.25VDC
• Output voltage: 0.5~4.5VDC ( Can be adjusted within 5VDC )
• Supply current: 10mA (Maximum)
• Load impedance: 10KQ ( Typical )
• Output response time:3ms
• Overvoltage protection: 40VDC
• Reverse voltage protection: -40VDC
• Short-circuit protection: Yes
• EMC withstand ( 1MHz——400MHz ) :100V/m
• ESD withstand:15KV
